ICE 125C specs
Right Click to download PDF above
ICE 125C

Vibrator Specifications

  • 12,500 inch-lbs — Eccentric Moment
  • 1500 vpm — Max Frequency
  • 415 tons — Driving Force
  • 400 tons — Centrifugal Force
  • .76 inch — Amplitude
  • 200 tons — Standard Line Pull
  • 200 tons — Max Line Pull

Power Pack Specifications
  • Twin Cat C15 — Engine
  • 1,190 — Rated HP
  • 1,900 rpm — Operating Speed
  • 5,500 psi — Max Motor Pressure
  • 275 gpm — Motor Flow
  • 4,500 psi — Clamp Pressure
  • 6 gpm — Clamp Flow
