ICE 44B specs
Right Click to download PDF above
ICE 44B

Vibrator Specifications

  • 4,400 inch-lbs — Eccentric Moment
  • 1800 vpm — Max Frequency
  • 207 tons — Driving Force
  • 202 tons — Centrifugal Force
  • 1.1 inch — Amplitude
  • 54 tons — Standard Line Pull
  • 80 tons — Max Line Pull

Power Pack Specifications
  • Cat C15 — Engine
  • 595 — Rated HP
  • 1,800 rpm — Operating Speed
  • 5,500 psi — Max Motor Pressure
  • 157 gpm — Motor Flow
  • 4,500 psi — Clamp Pressure
  • 6 gpm — Clamp Flow
Stacks Image 890
