ICE 66C specs
Right Click to download PDF above
ICE 66C

Vibrator Specifications

  • 6,600 inch-lbs — Eccentric Moment
  • 1600 vpm — Max Frequency
  • 242 tons — Driving Force
  • 240 tons — Centrifugal Force
  • 1.23 inch — Amplitude
  • 70 tons — Standard Line Pull
  • 95 tons — Max Line Pull

Power Pack Specifications
  • Cat C18 — Engine
  • 800 — Rated HP
  • 1,800 rpm — Operating Speed
  • 5,200 psi — Max Motor Pressure
  • 230 gpm — Motor Flow
  • 4,500 psi — Clamp Pressure
  • 6 gpm — Clamp Flow
Stacks Image 890
Information, Availability, Pricing:
phone: 877-546-6464 (toll free)
e-mail: info@jinnings.com
